SWL1850-6FR (6V 148Ah) Yuasa High Rate VRLA Rechargeable Battery
Please contact us to get the latest price for this product

1 in-stock.

Enter your postcode to get a quick quote for postage!

Tell a friend. Enter their email address here!

The Yuasa SWL range has been developed as a further enhanced version of the successful Yuasa NPL battery type, the result is a a battery with an improved energy to density ratio, boasting as much as 40% extra discharge capacity. This impressive power gain has been achieved without the requirement to change any other operating characteristic and so maintains the benefit of a common mechanical and electrical design for users of both products. The SWL range is able offer a further increase in choice for users of standby power products. The Yuasa SWL 1850 has a compact design providing excellent an power to footprint ratio, case material options, and ensures compliance with the high standards demanded by industry today. As with all Yuasa products, the Yuasa SWL 1850 battery has a proven, and well deserved reputation with engineers and those looking for a highly reliable standby power solution.


SPECIFICATIONS
WARRANTY12 Months
NameSWL1850-6FR (6V 148Ah) Yuasa High Rate VRLA Rechargeable Battery
CodeSWL1850FR
Nominal voltage12
AH148
AH RATING10-min rate Constant Power to 9.6V at 20°C
DIMENSIONS
Length350
Width166
Height174
Weight23

TERMINAL TYPE
Terminal TypeM6(F)
Torque4.8
OPERATING TEMPERATURE RANGE
Storage (in fully charged condition)-20°C to +50°C
Charge-15°C to +50°C
Discharge-20°C to +60°C
STORAGE
Capacity loss per month at 20°C (approx)3
CASE MATERIAL
Standard OptionABS (UL.94:HB)
Flame retardant option (FR)ABS (UL94:V0)
CHARGING
Float charge voltage at 20°C2.275 (±1%)
Float charge voltage at 20°C2.275 (±1%)
Float Charge voltage temperature correction factor (for variations from the standard 20°C)-3
Cyclic (or Boost) charge at 20°C2.42 (±3%)
Cyclic (or Boost) charge at 20°C2.42 (±3%)
Cyclic Charge voltage temperature correction factor (for variations from the standard 20°C)-4
Cyclic (or Boost) charge current limit 16.5
MAXIMUM DISCHARGE CURRENT
1 second800
1 minute500
SHORT-CIRCUIT CURRENT & INTERNAL RESISTANCE
Internal resistance (according to EN IEC 60896-21)9.35
Short-Circuit current (according to EN IEC 60896-21)1529
IMPEDANCE
Measured at 1 kHz5
