YPC100-12 (12V 100Ah) Yuasa General Use VRLA Rechargeable Battery
Please contact us to get the latest price for this product

1 in-stock.

Enter your postcode to get a quick quote for postage!

Tell a friend. Enter their email address here!

YPC100-12 Yuasa 12v 100Ah Rechargeable Battery - Ultra Performance New AGM Technology Yuasa YPC100-12 Batteries are one of the market leaders in manufacturing deep cycle batteries. Yuasa YPC100-12 - 12v 100Ah batteries are known for supreme quality and reliability, providing industry leading performance and long life, widely used for electric vehicles and other cyclic applications. These batteries feature low maintenance and valve regulated construction combined with heavy-duty plates and unique separator systems to deliver cyclic capability twice as long as conventional batteries, providing constant high performance and long life. For peace of mind these batteries are backed by full Manufacturer warranty support Features Supplied with 1 Year Manufacturer Warranty Support Brand New Fresh Stock for Maximum Performance YPC100-12 Battery 12v 100Ah Superior High Performance Battery - Supplied Fully Charged Can be used to replace Yuasa NP100-12, Genesis NP100-12, Yuasa YC100-12, Yuasa Y100-12 Longer lifespan due to Heavy-duty plates and unique separator systems to deliver cyclic capability twice as long as conventional batteries Quick Specs Voltage = 12 Volts Battery Capacity = 100 Ah Battery Type = AGM Deep Cycle Length = 330mm, Width = 173mm, Height = 212mm Weight: 30 Kg Terminal layout: Left: + Right: - Terminals on the edge nearest you Warranty 1 Year manufacturer warranty


SPECIFICATIONS
WARRANTY12 Months
NameYPC100-12 (12V 100Ah) Yuasa General Use VRLA Rechargeable Battery
CodeYPC100-12
Nominal voltage12
AH104
AH RATING20-hr rate Capacity to 10.8V at 20°C
DIMENSIONS
Length330
Width173
Height212
Height over Terminals220
Weight30

TERMINAL TYPE
Terminal TypeM8(F)
Torque14.7
OPERATING TEMPERATURE RANGE
Storage (in fully charged condition)-20°C to +60°C
Charge-15°C to +50°C
Discharge-20°C to +60°C
STORAGE
Capacity loss per month at 20°C (approx)3
CASE MATERIAL
Standard OptionABS (UL.94:HB)
Flame retardant option (FR)ABS (UL94:V0)
CHARGING
Float charge voltage at 20°C2.275 (±1%)
Float charge voltage at 20°C2.275 (±1%)
Float Charge voltage temperature correction factor (for variations from the standard 20°C)-3
Cyclic (or Boost) charge at 20°C2.42 (±3%)
Cyclic (or Boost) charge at 20°C2.42 (±3%)
Cyclic Charge voltage temperature correction factor (for variations from the standard 20°C)-4
Cyclic (or Boost) charge current limit 26
MAXIMUM DISCHARGE CURRENT
1 second1200
1 minute1040
IMPEDANCE
Measured at 1 kHz4.9
